BB60 Portable Line Boring Machine is an outstanding line borer in its class. No matter for excavator bucket repair, diesel repair, bore repair, pinhole reboring or any other hole reboring, BB60 is competent. Boring bar goes through the machine body which makes its installation flexible and makes sure the concentricity.
contact us right now for more info, or check out our entire line of line boring machines.
Standard Boring Bar (customizable)
60*2000 mm (2.36*78.74 Inches)
Boring Diameter
100-500 mm (3.93-19.69 Inches)
Customizable and with optional bar
Boring bar speed
0-140rpm
Axial Feed Speed
0-0.5mm(0.02 inches)/r
Installation
any position of the boring bar
Power Option
2.2 Kw electric motor
220V single phase or 380V three-phase powe
Aluminum alloy shell machine body, weight only 13Kg.
The boring bar goes through the machine body to ensure the coaxial of the mainbody and the boring bar. The machine body can be installed at any position of the boring bar and can be installed in a narrow space.
The patented feed mechanism is a reliable and durable structure with almost no fault.Infinite variable speed feed mechanism can achieve forward feed, reverse feed, and manual feed function.
Powerful AC 2.2Kw drive motor, variable speed control by frequency converter. General motor, stable, easy maintenance. The connection between the motor and the machine body is convenient to disassemble, and the suitable motor can be replaced according to the local conditions. Optional power supply: 220V single phase or 380V three-phase power.
Bearing mount assembly can be designed according to needs. Adjustable mechanism ensures the coaxality of boring bar, mainbody and bearing mount assembly.
Advanced worm gear reducer, high efficiency and high torque output, cutting ability 8mm in the radius.
The slotless structure avoids the bending deformation of the boring bar due to the machining stress.
Feed stroke can be easily changed.
Easy to operate with the remote handle. The electric control box is separated from the mainbody, avoiding the loosening of electric lines caused by the vibration the machining process.
